ATI 3FASS-010B ProRace Valve - Open with 3" Aluminum Flange BLK

ATI 3FASS-010B ProRace Valve - Open with 3" Aluminum Flange Black

ATI 3FASS-010B ProRace Valve - Open with 3" Aluminum Flange BLK

FREE SHIPPING! ATI 3FASS-010B ProRace Valve - Open with 3" Aluminum Flange Black

Please remember that the prices on our site are the Procharger Minimum Advertised Prices, Call 260 672-2076

3FASS-010B / PRORACE VALVE BAG Twice as much flow as a...

 Click on More Information link below



The Finer Details

Part Number: ATI 3FASS-010B

Manufacturer: ATI ProCharger (Accessible Technologies Inc)

Condition: New

Weight: 3 lbs


$0.00
$768.00
Earn0
reward points


ATI 3FASS-010B ProRace Valve - Open with 3" Aluminum Flange Black

Send this to a friend

ATI 3FASS-010B ProRace Valve - Open with 3" Aluminum Flange BLK


  • More Information

    FREE SHIPPING!

    ATI 3FASS-010B ProRace Valve - Open with 3" Aluminum Flange Black

    Please remember that the prices on our site are the Procharger Minimum Advertised Prices
    Call 260 672-2076


    3FASS-010B / PRORACE VALVE BAG

    Twice as much flow as a standard ProCharger Race Valve!!

    This all new ground up design from ProCharger will revolutionize how people look at bypass valves, this unit is the fastest and highest flowing valve ever created. This unit is still easily placed onto a 3" tube for use in tight engine bays, with simple V-band clamp installation.

    How about a valve that takes HALF the vacuum to operate (perfect for all out race motors, with large cams)
    How about TWICE the closing force then boost pressure (with no extra springs, or CO2)
    How about TWICE the flow of our standard race valve. (Save weight and $$ by using only one valve)

    We have been advising to not use the ProRace valves for regular street use, because the piston design can accumulate excessive debris with all of the grease. One guy who wasn't using inner fender wells ran into a problem with his clogging up. If you use it in a cleaner environment you may not run into any problems.

    Oh and one thing we can't forget, that killer "WHOSH" sound that only a ProCharger Race Valve can deliver!







    WHY ARE BYPASS VALVES IMPORTANT?

    For supercharging applications, surge occurs when excessive boost or pressure spikes as a result of a sudden throttle blade closing, which can cause severe damage to a supercharger and is why we mandate all ProCharger supercharger installations use a bypass valve.





    A SIMPLE WAY TO LOOK AT OUR OFFERINGS IS BASED ON YOUR ENGINE’S HORSEPOWER OUTPUT LEVEL:

    700 HP OR LESS - PROFLOW OR BULLET BYPASS VALVE IS RECOMMENDED, DEPENDING ON PREFERENCE

    ProFlow Valve: The ProFlow valve is the standard surge valve option for our street supercharger systems and kits. Compact in size. It can be fitted into tight spots when space is limited. Its butterfly valve is extremely durable and reliable, and this design creates a straight airflow path which achieves excellent flow for its size. The ProFlow valve can also be paired with a small air filter to minimize noise.

    Bullet Valve: This surge valve's compact design also makes it fit easily in tight spaces. It comes in both an open and closed format. The closed format allows you to recirculate air back into the system, or instead to run to an air filter to minimize noise.



    701-1200 HP - RACE OPEN BYPASS VALVE IS RECOMMENDED

    Race Valve: This is the industry leading surge valve for both street and race applications. The larger valve diameter is designed for high flow applications.



    1201-3500 HP

     Competition Valve: Designed with the Pro Mod racer in mind; compact, light and fast acting. For use as a pair in applications above 3,000 HP.

    ProRace Valve: One ProRace Valve outflows any other single valve on the market and is our highest-hp bypass valve option. This massive flow capacity comes from a piston style valve design (patent pending) that allows for  a significant increase in curtain area over traditional style valves, while still fitting into a reasonably sized package. It also incorporates a v-band clamp for an easy install.



    OPEN VS. CLOSED BYPASS VALVES

    Open – Vents to atmosphere and creates a distinctive “whoosh,” when the throttle blade suddenly closes, which a lot of people enjoy the sound.

    Closed – Vents to an external air filter or an internal tube for rerouting excess boost pressure back upstream of supercharger for a more quiet and subtle sound.  More ideal for street applications where someone wants more of a silent or stealth operation of the supercharger.

    For street applications, our complete systems and tuner kits come with the proper bypass valve based on the vehicle’s horsepower output level so, no need to worry about the right one. However, we do offer upgrade options for our Systems and Tuner Kits with our Race bypass valve family for those seeking a little more sound or those that like the cool look of the anodized finish of our Race bypass valves.





    BYPASS VALVES ARE NOT WASTE GATE RELIEF VALVES

    Contrary to most perceptions a bypass valve is designed to relieve boost/pressure when the throttle blade is closed.  Conditions such as idle, during shifts, and backing off throttle during tire slip conditions are very important to have a bypass valve.  A bypass valve utilizes a vacuum line port behind the throttle blade and vents when detecting an immediate change in pressure. Bypass valves are different from a wastegate relief valve, which operates as a pressure relief valve and opens or vents excess pressure when a certain pressure is achieved.



    WOULD YOU EVER WANT TO INSTALL A WASTE GATE RELIEF VALVE WITH A PROCHARGER SUPERCHARGER?

    The correct answer is no. Our superchargers are designed to provide maximum boost and efficiency at the maximum engine rpm and by adding a wastegate relief valve to vent that boost is defeating the whole purpose of having an efficient ProCharger supercharger.  Proper supercharger pulley size and knowing how much boost your engine can handle at its rated max rpm are the keys to success with a proper ProCharger setup.
