ATI 1FR200-F1 11-14  5.0 Intercooled Cog Race Kit with F-1D, F-1, F-1A

Now with crank support option!

ProCharger Intercooled Cog Race Kit

The Intercooled Cog Race Kit for 5.0 4V Mustangs utilize the patented, proven F-Series ProCharger supercharger drive system, a highly-effective, race air-to-air intercooler, OEM-quality mounting brackets, larger fuel injectors, higher capacity fuel system, tuning and all necessary supercharger and intercooler tubes for installation onto Mustangs with no major modifications to your car or engine. ProCharger Systems are 100% complete and require no additional hardware.

ATI 1FR200-F1 11-14  5.0 Intercooled Cog Race Kit with F Series with F-1D, F-1 &  F-1A

Note: ATI Balancer 918047 required for 10 rib and cog

Air to air race intercooler is standard

Race bypass valve is standard

Designed around an industry-exclusive, dedicated 50 mm wide cog drive belt, the new Cog Race Kit can mount a wide range of ProCharger supercharger models, including the F-1D, F-1, F-1A, F-1A-94, F-1C and F-1R. These models carry HP ratings from 1,000 up to 1,300+ HP. The Cog Race Kit also features a large, front-mounted air-to-air intercooler and legendary ProCharger race bypass valve.

CALIFORNIA EMISSIONS NON-COMPLIANCE INFO (CARB)

NOTE: ProCharger Race Kits for the 2011-2014 Ford Mustang are NOT legal for street use in California. These products are intended for racing or off road applications only. California approved products for street legal use (complete systems) will have an associated CARB EO# for compliance.  Click here for a full list of California and 50 state street legal systems.

Largest, Most Reliable Power Gains in the Industry

 Thanks to the dedicated supercharger drive system, highly efficient supercharger compressor design and effective, air-to-air intercooler system, ProCharger produces the largest power gains in the industry.

NGK 6510 sparkplugs gapped at .035” are recommended.

For the 2011+ 5.0L Mustang, the animation below illustrates (3) different intercooler options in the form of the HO intercooler system, Stage 2, and Race. The HO intercooler features a highly efficient crossflow intercooler core for stock or slightly modified applications. Our Stage 2 offering swaps to a large side to side flow core that is 3.5" thick offering great flow for modified applications pushing the power levels. For those going for the ultimate in charge cooling, the Race Intercooler with 4.5" thick core can be ordered that features a MASSIVE 1296 cubic/inch Cooling Core! As you can see all (3) intercoolers fit behind the factory 5mph impact bumper, and no modification to the car is needed for installation.

HO Intercooler = 540 cubic/in Cooling Core
Stage 2 Intercooler = 1008 cubic/in Cooling Core
Race Intercooler = 1296 cubic/in Cooling Core
